Part washer SteriWasher 1500 of manufacturer Suncombe | Pre-owned – Available Immediately
.
Premium Cleaning Solution for Regulated Industries
We offer a high-performance and proven parts washing system, SteriWasher 1500 manufactured by Suncombe, designed for use in regulated and quality-critical production environments.
The system enables reproducible, validatable and efficient cleaning of components ranging from small parts to large vessels and containers.
Key Benefits at a Glance
✔ Validatable cleaning processes for GMP-regulated environments
✔ High cleaning performance through advanced spray technology
✔ Large chamber size (1,500 × 1,500 × 1,500 mm)
✔ Flexible loading concept for a wide range of components
✔ Resource-efficient operation (water & energy saving)
✔ Robust stainless steel construction (316L) for long service life
Typical Applications
Suitable for use in:
- Pharmaceutical and biotechnology production
- Food and beverage industry
- Chemical and process industries
- Research and development environments
Typical components cleaned:
- Production equipment and machine parts
- Mixing vessels, drums and containers
- Tools and small components
- IBCs, bins and pallets
- Filling and packaging line components
These applications reflect typical use cases according to manufacturer information
Technical Highlights
- Hygienic washing chamber made of stainless steel 316L
- Crevice-free construction with optimized drainage design
- Automatic locking hinged door
- Inflatable door seal for full containment
- High-performance spray cleaning system with variable intensity
- Combination of high-energy impingement washing and efficient rinsing
- Chemical dosing system(s)
- Hygienic pumps and valve technology
- Stainless steel enclosure
- Optional: HEPA-filtered air drying and cooling
Automation & Process Control
- Recipe-controlled cleaning programs
- Multi-stage cleaning processes (e.g. pre-rinse, wash, rinse, drying)
- Control of temperature, pressure and flow rates
- Process documentation and traceability
Based on integrated automation and recipe-based control systems
Flexible Loading System
- Standard or custom-designed racks available
- External loading via mobile trolleys
- Defined positioning of components for reproducible cleaning results
Technical Specification
Construction & Materials
- Product contact parts: stainless steel 316L
- Non-product contact parts: stainless steel 304 (depending on configuration)
- Optional materials: Duplex or Hastelloy
- Hygienic, crevice-free washing chamber with sloped base
- Radiused internal corners for improved cleanability
- TIG welded construction
Built in accordance with common hygienic design principles
Standards & Compliance
- cGMP
- EHEDG
- ASME BPE
- GAMP
- 3A (depending on configuration)
Cleaning Process (CIP Principle)
Typical process steps include:
- Pre-rinse
- Chemical dosing and cleaning
- Recirculation cleaning
- Single-pass rinsing
- Final rinse
- Drain
- Air purge
- Self-CIP
Based on modular cleaning sequences described in system documentation
Automation System
- Multi-level automation with recipe management
- HMI interface with full system visualization
- Multi-level user access / password protection
- Process monitoring and diagnostics
- Optional electronic batch reporting and traceability
Loading & Handling
- Removable racks
- Loading via mobile trolleys
- Designed for validated positioning of components
Washing Chamber
- Dimensions: approx. 1,500 × 1,500 × 1,500 mm
- Material: stainless steel 316L
- Hygienic design
- Full sealing via inflatable door gasket
Technical Data (Excerpt)
- Operating temperature: up to approx. 95 °C
- Drying temperature: up to approx. 120 °C (optional)
- Power supply: 230 V / 400 V
- Cleaning system: spray-based
- Optimized for low water and energy consumption
Installation & Integration
- Suitable for standalone operation
- Can be integrated into existing production lines
- Applicable for production areas and cleanroom environments
Processing & Shipping
Condition & Availability
✔ Pre-owned system in good condition
✔ Available at short notice
✔ Inspection possible at any time
📍 Location: 28844 Weyhe near Bremen, Germany
Dismantling & Shipping
- Dismantling and packaging included (no additional cost)
- Worldwide shipping available (e.g. Incoterms DAP)
- Support with logistics and export handling
Request Your Offer
📧 info@s-vt.net
(please include your full company details)
Disclaimer
This is a non-binding offer by SEEFRIED Verfahrenstechnik GmbH as an independent supplier.
There is no commercial relationship with Suncombe Ltd.
All mentioned trademarks are the property of their respective owners and are used solely for identification purposes of the offered products.
This is not an offer by the manufacturer.
